1998 Jsw J650EII-12B

Have one to sell?
705-627-5456
sales@injectiondepot.ca
ConditionUsed
1 available
Have one to sell?

Overview

Type:
HORIZONTAL INJECTION MOULDING MACHINES
Manufacturer:
JSW
Model:
J720EII
Year:
1999
Status:
For Sale
Clamping Force Tonnage650 T589.671 t
Shot Volume (PS)91.7 oz2,599.1 g
Screw Diameter3.622"91.999 mm
Maximum Injection Pressure22188 psi
Maximum Holding Pressure22188 psi
Tie Bar Distance H37.4"949.96 mm
Tie Bar Distance V37.4"949.96 mm
Platen Dimension H53.94"1,370.1 mm
Platen Dimension V53.94"1,370.1 mm
Clamp Stroke37.4"949.96 mm
Maximum Daylight76.77"1,950 mm
Mold Height Min17.72"450.09 mm
Mold Height Max39.37"1,000 mm
Ejector Stroke7.09"180.09 mm
ControlCNC (syscom 1000)CNC (syscom 1000)
Dimensions37.07 Ft X 7.55 Ft X 7.87feet37.07 Ft X 7.55 Ft X 7.87feet
Weight63,93363,933

Barrel Type N-Aloy 60S
Hot Runner Manifold Zones :8
Hot Runner Nozzle Zones :4
Hydraulic Valve Gate : 2
Fixed Side Hydraulic Corepulls :1
Moving Side Hydraulic Corepulls :1
