Used 1999 UBE ULTIMA UN 950/159E | HORIZONTAL INJECTION MOULDING MACHINES

Have one to sell?
705-627-5456
sales@injectiondepot.ca
ConditionUsed
1 available
Have one to sell?

Overview

Type:
HORIZONTAL INJECTION MOULDING MACHINES
Manufacturer:
UBE
Model:
ULTIMA UN 950/159E
Condition:
Good
Year:
1999
Status:
For Sale
TypeHydraulicHydraulic
Clamping Force Tonnage950 T861.827 t
Shot Volume (PS)159.6 oz4,524.6 g
Screw Diameter3.94"100.08 mm
Tie Bar Distance H41.73"1,059.9 mm
Tie Bar Distance V41.73"1,059.9 mm
Platen Dimension H61.41"1,559.8 mm
Platen Dimension V61.41"1,559.8 mm
Clamp Stroke47.24"1,199.9 mm
Maximum Daylight94.48"2,399.8 mm
Mold Height Min19.69"500.13 mm
Mold Height Max47.24"1,199.9 mm
Ejector Force27.5 T24.948 t
Ejector Stroke27.5"698.5 mm
Power supply Volts460460
Injection OrientationHorzHorz
ControlCNC (UBE S3)CNC (UBE S3)
Dimensions450.94"L x 92.48"W x 111.13" H450.94"L x 92.48"W x 111.13" H
Weight103,635 Lbs.103,635 Lbs.

159.6 Oz. Injection Unit
Hydraulic Core-Pull Unit
SERVO Ejection
2-Cores on the Movable & 2-Cores Stationary Platen
6-Valve Gates
Star Robot, Model: TW-1500VI-480
