Used 1997 ENGEL ES7000/750WP | HORIZONTAL INJECTION MOULDING MACHINES
Have one to sell?
ConditionUsed
1 available
1997 ENGEL ES750
MODEL: ES7000/750WP
TONNAGE: 750 TON
SHOT SIZE: 176.2 OZ OZ
PLATEN DIMENSIONS (H X V): 64.30" x 66.73"
TIE BAR SPACING (H X V): 45.00" x 45.00"
CLAMP STROKE MAX: 35.43"
HYDROLIC EJECTOR STROKE: 9.84"
HYDROLIC EJECTOR FORCE: 12.4"
MIN/MAX DAYLIGHT: 15.75"/75.59"
MACHINE DIMENSIONS : 475" L x 128" W 102" H
MACHINE WEIGHT: 87000/46000 LBS
EQUIPPED WITH:
INPUT DRIVE: 60 HZ
INPUT PROCESS HEAT: 60 HZ
INTERRUPTING CAPACITY: 10,000 AMPS
