Overview

Type:
HORIZONTAL INJECTION MOULDING MACHINES
Manufacturer:
SUMITOMO
Model:
SE350HSZ-C1250
Year:
2015
Status:
For Sale
TypeAll ElectricAll Electric
Clamping Force Tonnage385 T349.267 t
Shot Volume (PS)24.4 oz691.7 g
Screw Diameter2.48"62.992 mm
Maximum Injection Pressure25033 psi
Screw Speed High Torque320 rpm320 RPM
Plasticizing Capacity (PS) STD10,224 oz289,845.2 g
Tie Bar Distance H29.13"739.9 mm
Tie Bar Distance V27.95"709.93 mm
Platen Dimension H43.13"1,095.5 mm
Platen Dimension V40.16"1,020.1 mm
Clamp Stroke27.56"700.02 mm
Maximum Daylight53.94"1,370.1 mm
Mold Height Min15.94"404.88 mm
Mold Height Max26.38"670.05 mm
Ejector Force6.6 T5.987 t
Ejector Stroke5.91"150.11 mm
Power supply Volts460460
Hours6,285 hr.6,285 hr.
ControlCNC (NC5)CNC (NC5)

Features: High Speed
- Robot Interface
- 5 additional machine condition output signals
- Pneumatic Ejector Needle Valve Drive Circuit
- 2 additional dry contacts for Semi Automatic & Coo
Features: Valve Gate
