options:
Hydraulic Core-Pull Power Unit 7GPM @ 1,000psi
Transformer for 460V
Anti-wear single flight screw & Tungsten Carbide Barrel
Type
All Electric
All Electric
Clamping Force Tonnage
110 T
99.79 t
Barrel Code
2A
2A
Shot Volume (PS)
3.3 oz
94.1 g
Shot Volume (PE)
2.6 oz
75.1 g
Screw Diameter
1.26"
32.004 mm
Maximum Injection Pressure
31900 psi
Maximum Holding Pressure
31900 psi
Screw Speed STD
390 rpm
390 RPM
Screw Torque STD
lbf ft
lbf ft
Plasticizing Capacity (PS) STD
0.6 oz
17 g
Nozzle Touch Force
2 T
1.814 t
Tie Bar Distance H
18.1"
459.74 mm
Tie Bar Distance V
16.1"
408.94 mm
Platen Dimension H
26"
660.4 mm
Platen Dimension V
24"
609.6 mm
Clamp Stroke
13.8"
350.52 mm
Maximum Daylight
35.4"
899.16 mm
Mold Height Min
7.1"
180.34 mm
Mold Height Max
21.7"
551.18 mm
Ejector Force
3.3 T
2.994 t
Ejector Stroke
3.45"
87.63 mm
Main Breaker Electric Capacity
35 kw
Heater Capacity
6.8 kw
6.8 kW
Injection Orientation
Horz
Horz
Machine under power
Under power running with mould
Under power running with mould
Control
CNC (InjectvisorV50)
CNC (InjectvisorV50)
Dimensions
15.1 x 4.3 x 5.6
15.1 x 4.3 x 5.6
Weight
9,200
9,200
