2012 sumitomo SE75-DUZ-C160
Have one to sell?
ConditionUsed
1 available
Air Blow
Wired for Core Pull
Imperial
| Type | All Electric |
| Clamping Force Tonnage | 75 T |
| Shot Volume (PS) | 1.7 oz |
| Screw Speed STD | 400 rpm |
| Nozzle Touch Force | 0.8 T |
| Tie Bar Distance H | 16.14" |
| Tie Bar Distance V | 14.17" |
| Platen Dimension H | 22.83" |
| Platen Dimension V | 20.87" |
| Maximum Daylight | 27.93" |
| Mold Height Min | 6.3" |
| Mold Height Max | 16.14" |
| Ejector Force | 2.72 T |
| Ejector Stroke | 3.14" |
| Power supply Volts | 230 |
| Hours | 57,190 hr. |
| Machine under power | Under power running with mould |
| Control | CNC |
Air Blow
Wired for Core Pull
