| Clamping Force Tonnage | 110 T | 99.79 t |
| Barrel Code | A | A |
| Shot Volume (PS) | 7.4 oz | 209.8 g |
| Screw Diameter | 1.57" | 39.878 mm |
| Maximum Injection Pressure | 28600 psi | |
| Screw Speed STD | 260 rpm | 260 RPM |
| Injection Rate High Speed | 9 ft³/min. | 0.3 m³/min. |
| Screw Torque STD | -509 | -509 |
| Plasticizing Capacity (PS) STD | 0.9 oz | 25.5 g |
| Tie Bar Distance H | 18.1" | 459.74 mm |
| Tie Bar Distance V | 16.1" | 408.94 mm |
| Platen Dimension H | 26" | 660.4 mm |
| Platen Dimension V | 24" | 609.6 mm |
| Maximum Daylight | 31.5" | 800.1 mm |
| Mold Height Min | 7" | 177.8 mm |
| Mold Height Max | 17.7" | 449.58 mm |
| Ejector Force | 5.1 T | 4.627 t |
| Ejector Stroke | 4.7" | 119.38 mm |
| Heater Capacity | 11.2 kw | 11.2 kW |
| Injection Orientation | Horz | Horz |
| Hours | 24,000 hr. | 24,000 hr. |
| Weight | 9480 | 9480 |
opening stroke - 13.8 in
oil tank capacity - 79.3 GAL
Net weight without oil- Lbs 9480
Options:
Air Blow
Hydraulic Knock Out
press can be seen under power under power if needed.
Material Polyethylene, polypropylene, HDPE.
This equipment has been sold. Similar equipment available now is shown below.
