Used 2005 NISSEI NEX4000-36E | HORIZONTAL INJECTION MOULDING MACHINES

Have one to sell?
705-627-5456
sales@injectiondepot.ca
ConditionUsed
1 available
Have one to sell?

Overview

Type:
HORIZONTAL INJECTION MOULDING MACHINES
Manufacturer:
NISSEI
Model:
NEX4000-36E
Year:
2005
Status:
For Sale
TypeAll ElectricAll Electric
Clamping Force Tonnage198 T179.623 t
Shot Volume (PS)11.8 oz334.5 g
Tie Bar Distance H20.87"530.1 mm
Tie Bar Distance V20.87"530.1 mm
Platen Dimension H31.5"800.1 mm
Platen Dimension V31.5"800.1 mm
Clamp Stroke17.7"449.58 mm
Maximum Daylight37.8"960.12 mm
Mold Height Min9.8"248.92 mm
Mold Height Max20.1"510.54 mm
Power supply Volts230230
Injection OrientationHorzHorz
Hours33,398 hr.33,398 hr.
Machine under powerUnder power running with mouldUnder power running with mould
ControlCNC (TACT)CNC (TACT)
Weight16,755 lbs16,755 lbs

2005 198 TON NISSEI NEX4000-36E

​MODEL: NEX4000-36E
TONNAGE: 198 TON
SHOT SIZE: 11.8 OZ
PLATEN SIZE: 31.5" x 31.5"
TIE BAR SPACING: 20.87"
CLAMP STROKE: 17.7"
CONTROLLER: TACT CONTROL
VOLTAGE: 230V
MOULD HEIGHT: 9.8" - 20.1"
MAXIMUM DAYLIGHT: 37.8"
WEIGHT: 16,755LBS
MACHINE HOURS: 33,398
